LM Series
 |
||||||||||||||||||
| LM Series | ||||||||||||||||||
|
Bearing No. |
No. Of Ball Rows |
Main Dimensions |
Eccentiricit (Max.) |
Basic Load Rating |
Weight (g) |
|||||||||||||
|
Inscribed Circle Dia |
Outer Dia | Length |
Outer Locking Groove |
W | H | H1 | θ | |||||||||||
| dr | Tolerance | D | Tolerance | L | Tolerance | B | Tolerance | D1 |
Dynamic (kgf) |
Static Co (kgf) |
||||||||
| LM3 | 4 | 3 | 0 -0.008 | 7 | 0 -0.009 | 10 | 0 -0.12 | 0.008 | ||||||||||
| LM4 | 4 | 4 | 8 | 12 | 9 | 13 | 3 | |||||||||||
| LM5 | 4 | 5 | 10 | 15 | 10.2 | 0 -0.20 | 9.6 | 1.1 | 17 | 21 | 4 | |||||||
| LM6UU | 4 | 6 | 0 -0.009 | 12 | 0 -0.011 | 17 | 0 -0.20 | 13.5 | 11.5 | 1.1 | 1 | 0.012 | 21 | 27 | 6 | |||
| LM8S | 4 | 8 | 15 | 19 | 11.5 | 14.3 | 1.1 | 1 | 18 | 23 | 9 | |||||||
| LM8UU | 4 | 8 | 15 | 24 | 17.5 | 14.3 | 1.1 | 1 | 27 | 41 | 14 | |||||||
| LM10UU | 4 | 10 | 19 | 0 -0.013 | 29 | 22 | 18 | 1.3 | 1 | 6.8 | 80° | 38 | 56 | 28 | ||||
| LM12UU | 4 | 12 | 21 | 30 | 23 | 20 | 1.3 | 1.5 | 8 | 80° | 42 | 61 | 32 | |||||
| LM13UU | 4 | 13 | 23 | 32 | 23 | 22 | 1.3 | 1.5 | 9 | 80° | 52 | 79 | 38 | |||||
| LM16UU | 5 | 16 | 28 | 37 | 26.5 | 27 | 1.6 | 1.5 | 11 | 80° | 79 | 120 | 74 | |||||
| LM20UU | 5 | 20 | 0 -0.010 | 32 | 0 -0.016 | 42 | 30.5 | 30.5 | 1.6 | 1.5 | 11 | 60° | 0.015 | 88 | 140 | 80 | ||
| LM25UU | 6 | 25 | 40 | 59 | 0 -0.30 | 41 | 0 -0.30 | 38 | 1.85 | 2 | 12 | 50° | 100 | 160 | 206 | |||
| LM30UU | 6 | 30 | 45 | 64 | 44.5 | 43 | 1.85 | 2.5 | 15 | 50° | 160 | 280 | 240 | |||||
| LM35UU | 6 | 35 | 0 -0.012 | 52 | 0 -0.019 | 70 | 49.5 | 49 | 2.1 | 2.5 | 17 | 50° | 0.02 | 170 | 320 | 370 | ||
| LM40UU | 6 | 40 | 60 | 80 | 60.5 | 57 | 2.1 | 3 | 20 | 50° | 220 | 410 | 589 | |||||
| LM50UU | 6 | 50 | 80 | 100 | 74 | 76.5 | 2.6 | 3 | 25 | 50° | 390 | 810 | 1480 | |||||
| LM60UU | 6 | 60 | 0 -0.015 | 90 | 0 -0.022 | 110 | 85 | 86.5 | 3.15 | 3 | 30 | 50° | 0.025 | 480 | 1020 | 1750 | ||
