PRODUCT CATALOGUE
Section Diagram of the Seals
Section Diagram of the Seals |
||||||
| Model No. | Section | Temperature | Speed | Pressure | Material | Description |
| G01 |
 |
-30℃~ +100℃ | 0.5m/s | 70MPa | PU NBR |
Combination Seals, double action, combined by support ring, sealing ring and elastic body. The stable structure provide perfect sealability and pressurization for the seals. |
| G01H |
 |
-30℃~ +100℃ | 0.5m/s | 150MPa | PU NBR POM |
Combination Seals, double action, combined by thickening axial T guide ring, sealing ring and elastic body. The stable structure provides perfect sealability and pressurization for the seals. Mainly used for mine industries. |
| G02 |
 |
-30℃~ +100℃ | 0.5m/s | 70MPa | PU NBR POM |
Combinatioin Seals, double action, combined by retaining ring, sealing ring and elastic body. The stable structure provides perfect sealability and pressurization for the seals. Mainly used for mine industries. |
| G02H |
 |
-30℃~+100℃ | 0.5m/s | 150MPa | PU NBR POM |
Combination Seals, double action, combined by retaining ring, sealing ring and elastic body. The stable structure provides perfect sealability and pressurization for the seals. Mainly used for mine industries. |
| SH |
 |
-30℃~ +100℃ | 0.5m/s | 70MPa | PU NBR POM |
Combination Seals, double action, combined by support ring, sealing ring and elastic body. The stable structure provides perfect sealability and pressurization for the seals. |
| NL |
 |
-30℃~ +100℃ | 0.5m/s | 70MPa | PU NBR POM |
Piston Rod Seals, single action, special insert type groove allow the seals to bear high pressure, and get more extrusion space. |
| JF |
 |
-30℃~+100℃ | 0.5m/s | ---- | PU |
Standard Dust Proof Seals, single action, the extruded assemble method prevents dust and fouling very effectively, and also, helps the remain oil to inverse flow. |
| JFH |
 |
-30℃~ +100℃ | 0.5m/s | ---- | PU |
Standard Dust Proof Seals, mainly used for sealing system of the mining industries, the extruded assemble method and special lip design prevents dust and fouling very effectively. |
| JM |
 |
-30℃~ +100℃ | ---- | 70MPa | PU |
Special insert type groove with stable structure, allow the seals to be used for different application. |
| YL |
 |
-30℃~+100℃ | ---- | 70MPa | PU |
The extruded assemble method and stable insert type groove design, allow the seals to be used in different application with high pressure. |
| FQ |
 |
-50℃~ +120℃ | 0.5m/s | ---- | FQ |
The intensive phenolic resin guidance tape provides anti-load function and anti-friction function, and also, it provides self-lubricating ability. This kind of seal were widely used for mining industries. |
